2024 best 4x4 hobby CNC router kit with four spindles is the best solution for advertising, woodworking, arts, crafts and other small business, the best 4x4 CNC table kit can process four pieces at one time to save time and improve the efficiency.
The 4x4 CNC router is great for enthusiasts since it delivers just the right size and power. Its size is just right—it can manage a range of tasks without being overly large. Regardless of your level of skill with CNC machining, this machine is compact enough to fit nicely in a home workshop.
The 4x4 size is perfect for amateurs with limited space because it may fit in a garage or basement. To use it, you don't need a large workshop. In contrast to large CNC machines, a 4x4 type is less expensive. It delivers results of a professional caliber without the hefty price tag.
A lot of 4x4 CNC routers include easily comprehensible software. This implies that even if you're new to CNC machining, you can get started on tasks right away. Aluminum, plastic, and wood are among the materials that the 4x4 CNC router can work with. This machine is capable of producing signage, decorations, and furniture.
Compared to larger industrial models, this machine is easy to move even though it is still durable and powerful. Rearranging your workstation or moving it to a new location can be accomplished with minimal difficulty.
If you want to increase production and develop more intricate items, a 4-spindle CNC router is a wise investment. A machine with numerous spindles may complete several jobs at once, which can result in significant time savings. Additionally, it allows enthusiasts to effortlessly switch between tools.
1. Increased Efficiency: This machine is ideal if you're working on a huge project with lots of parts because it has 4 spindles, which allow it to accomplish multiple operations without stopping to change tools manually.
2. More Design Possibilities: Having more than one spindle enables you to make intricate and sophisticated designs. Different materials can be drilled, engraved, and cut without the need for additional equipment.
3. Perfect for Repetitive Tasks: The 4 spindles cooperate to speed up the process of creating several copies of the same pattern. You can therefore make more goods in less time.
4. Ideal for Multi-Tool Operations: Every spindle can hold a distinct set of tools. For instance, 3 spindles can be configured: one for drilling, one for engraving, and one for cutting. For projects that call for various procedures on the same piece, this configuration is perfect.
5. Saves Time and Effort: The machine automatically switches between spindles rather of needing to stop all the time to change tools or modify parameters. This expedites the project and lessens your workload.
1. The 4x4 hobby CNC router can process several pieces at one time to save time and improve efficiency. It can also work separately only one head to process and increase the working area.
2. The 4x4 hobby CNC machine adopts a 4pcs*2.2KW water-cooling spindle and is also good at engraving on brass, aluminum, plastic, acrylic, wood, MDF, and other similar materials.
3. The hobby CNC machine is working with a dust hood on all 3 axes, it can stop dust away from the rails and ball screws, and it can also keep the machine working for a longer time.
4. The hobby CNC router adopts a Taiwan TBI ball screw, it can keep high precision to do fine engraving.
5. The 4x4 CNC router adopts a T-slot & vacuum table, holding the small materials with clamps and holding the full size with a vacuum table and pump, With high accuracy, you can do many jobs for advertisement decoration, sign making, label industry, woodworking, mold making, architectural model, marble carving as well as art crafts and gifts industry.
6. The 4x4 CNC machine adopts intelligent protection of the working table, which can avoid damage resulting from the wrong operation. Intelligent over-running protection can avoid mechanical collision when the set graphic exceeds the processing size.
| Model | STG1212-4 |
| Working Area | 1200x1200x120mm |
| Table Size | 1340X1545mm |
| Traveling Positioning Accuracy | ±0.03/300mm |
| Repositioning Positioning Accuracy | ±0.04mm |
| Lathe Structure | Cast Steel |
| X, Y Structure | Ball Screw, Shaft Linear Bearings |
| Z Structure | Ball Screw, Shaft Linear Bearings |
| Max. Consume Power | 3.5Kw |
| Max. Speed | 0-18000mm/min |
| Max. Working Speed | 0-8000mm/min |
| Spindle Power Motor | 2.2kw water-cooling spindle |
| Spindle Speed | 0-24000RPM |
| Drive Mode | Stepper Motor |
| Working Voltage | AC220V/50/60Hz |
| Command | G Code, *uoo, *mmg, *plt |
| Operating System | DSP or NC-STUDIO Control System |
| Interface | USB |
| Flash Memory | 128M |
| Collet | ER20 |
| X-Y-Z Working Delicacy | <0.01mm |
| Software | Type3, Ucancam, Artcam |
| Running circumstance | Temperature: 0°C~45°C Relative humidity: 30%~75% |
| Packing Size | 1800x1830x1450mm |
| Net Weight | 600KG |
| Gross Weight | 750KG |
Advertisement
Engraving and cutting various labels and number plates.
Woodworking
Processing of various furniture such as doors, windows, cabinets, craft wood doors, screens, and so on.
Arts and Crafts
Engraving characters of any language and graphics on souvenirs.
1. 4x4 hobby CNC Router STG1212 with 4 spindles adopts a Yaskawa servo motor to keep high precision and strength, it can also use a steeper motor.
2. The NC studio control system can be instead of the NK105 DSP control system.
3. Along with the 4x4 hobby CNC router STG1212 with 4 spindles, some spare parts, work fixtures, and tools will be packed into the tool kit.
4. The whole machine will be wrapped with cling plastic and then packed into a wooden case.
The 4th rotary axis is optional for this 4x4 hobby CNC router with 4 spindles to work on some 3D woodworking projects such as table legs, Buddha heads, and stair spindles.
To keep your 4x4 CNC router operating smoothly and prevent malfunctions, it's essential to maintain it. The machine will survive for many years and remain in good shape with regular care. Here are a few easy maintenance suggestions to keep your equipment operating at its best.
• Clean the Machine Regularly: Dust and debris can build up on the router, especially if you’re working with wood. Make sure to clean the cutting area after each use.
• Check the Spindles: Since you have 4 spindles, it’s important to check them for wear and tear. If any spindle isn’t working as well as it should, replace or repair it quickly.
• Lubricate Moving Parts: The machine has many moving parts, like rails and bearings, that need to stay lubricated. Apply light oil or grease regularly to keep everything running smoothly.
• Tighten Loose Screws and Bolts: Over time, the machine’s vibrations can cause screws and bolts to loosen. Check all fasteners regularly and tighten them to avoid accidents or damage.
• Monitor the Software: Ensure that the CNC software you’re using is up to date. Regular updates can improve performance and add new features.
• Inspect the Cutting Tools: Sharp cutting tools are essential for accurate results. If you notice dullness in the bits or tools, sharpen or replace them to maintain precision.
• Check the Cooling System: If your machine has a cooling system, make sure it’s working properly. Overheating can damage both the machine and the material you’re cutting.
• Store in a Dry Place: When not in use, store your CNC router in a dry environment to prevent rust and corrosion on the metal parts.
